OPERATION
Rot iss erie ▪ O p era tor’ s Ma n u al ▪ M N- 3940 4 ▪ Re v 1 ▪ 1 /1 9
43
Continued from previous page
Optional basket spits To load optional basket spits, do the following.
7. Insert the smooth pin h end in first when inserting the basket.
8. Load the baskets one at a time and as evenly spaced as possible. This is done
to maintain balance within the rotisserie.
Optional turkey spits To load optional turkey spits, do the following.
9. Insert the whole turkey with the legs facing the stop plate of the spit. Adjust
the stopping tab
j to keep the turkey in position.
Load one (1) turkey spit with a maximum weight of 25 lb (11.4 kg).
Use one (1) to three (3) turkey spits per oven for a maximum capacity of
three (3) whole turkeys.
Result You have now loaded the spits.
NOTE: Remove the machined pin i first when
removing the baskets.
