• Connect the test probes (N) in parallel to the
circuit under test.
• The stabilized value on the display (A) is read as
the actual reading.
Frequency mode (mV~)
• In AC voltage measurement mode, press the
Hz/% button (I). Hz (Hertz) lights up.
• Connect the test probes (N) in parallel to the
circuit or component being measured.
• The stabilized value on the display (A) is read as
the actual reading.
Duty Cycle mode (mV~)
• In AC voltage measurement mode, press the
Hz/% button (I) twice. % (percent) lights up.
• Connect the test probes (N) in parallel to the
circuit or component being measured.
• The stabilized value on the display (A) is read as
the actual reading.
AC/DC current measurement
NOTICE
Do not make 10A current
measurements for longer than 30seconds.
Exceeding 30seconds may cause damage to the
product and/or the connector leads (N).
