Product description
AMALOG BAH0017.1 11.08
11
3 Product description
This section:
• Provides a comprehensive overview of the structure.
• Designates the individual subassemblies.
Main subassemblies of the on-board computer
Fig. 1
Fig. 1/...
(1) Computer with fixing console
(2) Socket connection, 12V
(3) 20-pin connector with cable harness
