Use
AMALOG BAH0017.1 11.08
31
6. Stop after exactly 100 m.
→ The display (Fig. 28) shows the calibration
value
(e.g. 1005 imp./100 m).
7. Press
key.
→ Store the calibration value (imp./100 m).
8. Enter the calculated calibration value in the
table (Fig. 29) (recommendation).
Fig. 28
Display the stored value: Press key.
The calibration value (imp./100 m) must not be less than 250.
The
otherwise does not work properly.
If the calibration value deviates from the table values (Fig. 22 to Fig.
25)
• Again calculate the number of crank turns for the calibration test
(see section 7.1.2.1, on page 32)
• Enter the number of crank turns in the table (Fig. 29)
• Carry out a calibration test with the calculated number of crank
turns (see seed drill operating manual).
Field
Calibration value
"imp./100 m"
Crank rotations
Fig. 29
