Attaching and removing the machine at the tractor's rear three-
point linkage
Super SMARTCUT BAF0009.3 05.17
5.4.2 Disconnecting hydraulic hose lines
1. Swivel the actuation lever on the tractor control unit on the trac-
tor to float position (neutral position).
2. Unlock the hydraulic connectors from the hydraulic sockets.
3. Protect the hydraulic plug and hydraulic socket against soiling
using the dust protection caps.
4. Store the hydraulic hose lines in the hose cabinet.
