Adjusting the cutting height
Super SMARTCUT BAF0009.3 05.17
• Select the required working height via the height-adjusting
screw (Fig. 7-3)
• Tighten the clamping screw (Fig. 7-2)
Care must be taken to ensure that the cage roller is equally adjusted
on both sides. For this purpose, a check scale has been fitted (Fig. 7-
4).
