Figure 6
4. Display Features
4.1 Comfort Icon
The comfort icon is based on humidity ranges specified in Figure 7 . The icon
is displayed for indoor humidity, remote channel 1 humidity and optional remote
channels 2 through 8 humidity.
Figure 7
4.2 Rate of Change Icon
The rate of change icon detects rapid changes in temperature and humidity.
If the arrow points upward, the temperature is increasing at a rate of +2°F per
30 minutes (or greater), or humidity is increasing at a rate of +5% per 30
minutes (or greater). If the arrow points downward, the temperature is
decreasing at a rate of -2°F per 30 minutes (or less), or humidity is decreasing
at a rate of -5% per 30 minutes (or less).
5. Console Operation
Note: The console has three buttons for easy operation: CLEAR/- button,
SET/ADJUST button, and CHANNEL/+ button.
5.1 Set Mode
The Set Mode allows you to set the date and time, date and time format, and
units of measure.
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 7
RH<45% RH45%~65% RH>65%
Dry
Comfortable
Wet
