AMBROGIO BASIC - Page 24

- 24 -
C141501700.fm
User's manual
GB
2-Remove the hood (B).
3-Undo the bolts (C) and remove
the guard (D).
4-Unscrew the nuts (E) and un-
thread the brackets (F).
IDM - 41501702100.tif
guard (D)
screw (C)
screw (C)
screw (C)
IDM - 41501702200.tif
nut (E)
bracket (F)
bracket (F)
IDM - 41501702000.tif
hood (B)
