30
Preview Control Interface
Move your mouse near the center at the top of the video of the current channel. You will notice that the system pops
up the preview control interface as shown below.
If your mouse stays in this area for more than 6 seconds without any action, the control bar will auto-hide.
1 2 3 4 5
1. Mute
Click to mute. Click again to enable audio when in preview mode.
Please note that this function only works when viewing one window/channel.
2. Digital zoom
This is used to zoom into a specified zone of the current channel.
Click the button, and the button will then show as .
There are two ways for you to zoom in.
• Click and drag the mouse to select a zone. You can see the interface shown below.
• Push the middle mouse button at the center of the zone you want to zoom into, and move the mouse. You
can see the interface as shown below.
Right click the mouse to cancel zoom and go back to the original interface view.
3. Manual record function
This is used to back up the current channel’s video to the USB device. The DVR cannot backup multiple channels of
video at the same time.
Click the button begin recording. Clicking it again causes the system to stop recording. You can find recorded
files on the flash drive.
4. Real-time playback
This button is used to playback the previous 5-60 minutes recorded from the current channel.
Please go to the Main menu->Setting->->System->General screen to set real-time playback.
The system may pop up a dialog box if there are no recordings on the current channel.
5. Manual Snapshot
