32
Note: The name of the command will be grayed out if the function is not supported.
Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light, wiper,
rotation, etc.
The speed field controls PTZ movement speed. The value ranges from 1 to 8. 8 is the fastest and 1 is the slowest.
The remote control’s numeric keypad can be used to enter in a value.
To adjust values for Zoom, Focus, and Iris, click the buttons on either side of the function to adjust them. The
following chart will provide guidance on how to use the buttons to adjust the PTZ functionality.
The PTZ control panel also supports the rotation of the camera in 8 different directions. If the buttons on the front
panel of the DVR are used, then only four of the directions will be accessible (up/down/left/right).
In the middle of the eight directional arrows, there is a button to activate the 3D Intelligent Positioning function.
To use the 3D Intelligent Positioning function, your PTZ enabled device should support this function, and a
compatible USB mouse should be plugged into the DVR.
By clicking the button and activating the 3D Intelligent Positioning, the system will go to single screen mode.
Once activated, section size can be adjusted using the mouse. The zone selected supports 4x to 16x speeds and can
use PTZ automatically to move the camera field. The smaller the designated zone, the higher the movement speed
within the zone.
Additional functions within the PTZ control panel can be opened by clicking the button. See the chart below to
see which additional functions are available.
