Jumpers
Jumper Name Description Page
JP1 Keyboard/USB Power On Enabled/Disabled 3-pin Block P.8
JBAT CMOS Clear 3-pin Block P.8
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket AM3 CPU Socket 941-pin PGAB AM3 CPU Socket P.10
DDRIII1~DDRIII4 DDRIII Module
Socket
240-pin DDRIII Module Socket P.11
PE1,PE4 PCI-Express2.0 x16
Slot
PCI-Express 2.0 x16 Expansion Slot P.12
PE2 PCI-Express x1Slot PCI-Express x1 Expansion Slot P.12
PCI1 PCI Slots 32-bit PCI Local Bus Expansion slots P.12
Connectors
Connector Name Description Page
ATXPWR1 ATX Power Connector 24-pin Block P.13
ATX12V ATX 12V Power Connector 8-pin Block P.14
KB PS/2 Mouse & PS/2 Keyboard
Connector
6-pin Female P.14
USB from
USB-B1/UL1
USB2.0 Port Connector 4-pin Connector P.14
RJ-45LAN from UL1 Gigabit LAN Port Connector 8-pin Connector P.14
J1 8-CH HD Audio Connector 6- phone jack Conn. P.15
IDE1 Primary IDE Connector 40-pin Block P.15
SATA1~SATA6 Serial ATAII Connectors 7-pin Connector P.15
VGA D-Sub Video Graphics Adapter
Connector
15-pin Connector P.15
DVI1 Digital Visual Interface 24-pin Connector P.15
HDMI High-Definition Multimedia 19-pin Connector P.15
SPDIF_OUT1
/SPDIF_OUT2
Coaxial /Optiocal HDMI-SPDIF Out
Connector
1-phone Connector P.16
Headers
Header Name Description Page
AUDIO1 Front Panel SPEAKER, MIC header 9-pin Block P.16
USB1, USB2 USB Port Headers 9-pin Block P.16
SPEAK1 PC Speaker connector 4-pin Block P.16
PWR LED1 Power LED 3-pin Block P.16
JW
_
FP1
(Reset/Power on/
HD LED/Power LED)
Front Panel Header
(including IDE activity LED/Reset
switch / Power On Button lead)
9-pin Block P.16
SYSFAN1,SYSFAN2 FAN Headers 3-pin Block P.17
CPUFAN FAN Header 4-pin Block P.17
CDIN1 CD Audio-In Header 4-pin Block P.17
IR IR infrared module Headers 5-pin Block P.18
COM1 Serial Port COM1 Header 9-pin Block P.18
HDMI-SPDIF SPDIF Out header 2-pin Block P.18
