30
3-10 PC Health Status
This section shows the Status of you CPU, Fan, and Warning for overall system status.
This is only available if there is Hardware Monitor onboard.
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
PC Health Status
Help Item
PC Health Status
¾
Smart FAN Configuration Press Enter
H/W Health Function Enabled
CPU Temperature: : 59
°
C/138
°
F
System Temperature: : 40
°
C/104
°
F
CPUFAN1 Speed: : 2923RPM
SYSFAN1 Speed: :N/A
SYSFAN2 Speed: :N/A
VCore :1.355V
+5V :4.918V
+12V :12.056V
5VSB :5.045V
VDIMM :1.599V
↑↓ : Move Enter: Select +/-
: Value F10: Save ESC: Exit F1: General Help
F5: Discard Charges F6: Standard Defaults F7: Optimized Defaults
H/W Health Function,
It displays information list below when set as below. The choice is either Enabled or
Disabled.
CPU Temperature/ System Temperature/ CPUFAN1 Speed /SYSFAN1
Speed/SYSFAN2 SpeedVCore/+5V/+12V/5VSB/ VDIMM
This will show the CPU/ /System voltage chart and FAN Speed, etc.
3-10-1 Smart FAN Configuration
CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Smart FAN Configuration
Help Item
Fan1 Mode Setting Auto Fan by Duty
Temperature1 Limit of Highes 050
Temperature1 Limit of Second 040
Temperature1 Limit of Third 030
Temperature1 Limit of Lowest 020
Fan configuration
mode setting
↑↓ : Move Enter: Select +/-
: Value F10: Save ESC: Exit F1: General Help
F5: Discard Charges F6: Standard Defaults F7: Optimized Defaults
Smart FAN Configurations FAN1 Mode Setting
The optional settings are: Auto Fan by RPM; Auto Fan by Dutycycle; Manual Mode by
RPM and Manual Mode by Dutycycle.
3-11 Thermal Throttling Options
CMOS Setup Utility-Copyright(C) 1985-2005 American Megatrends. Inc.
Thermal Throttling Options
Help Item
CPU Thermal-Throttling Enabled
CPU Thermal Throttling Temp 70
CPU Thermal Throttling Duty 50%
Options
Disabled
Enabled
↑↓ : Move Enter: Select +/-
: Value F10: Save ESC: Exit F1: General Help
F5: Discard Charges F6: Standard Defaults F7: Optimized Defaults
