Version 0A 19
Operating Frequency Range
This amplifier covers all Amateur Radio frequencies below 54 MHz, as restricted by
FCC or your local governing authority. Once you have established proper connections,
please set the amplifier BAND SELECT control (Fig. 2, ref 3) to one of the following
bands:
Band Frequency
Range
Notes
160 1.8 - 2.1 MHz
80 3.2 - 4.2 MHz
40 6.0 - 7.5 MHz
30 7.5 - 14.5 MHz USA 30-meter power limit currently 200-watts
20 7.5 – 14.5 MHz
17 14.5 – 22.0
MHz
15 14.5 – 22.0
MHz
12 22.0 – 30.0
MHz
Amplifier automatically disables above 25 MHz
10 22.0 – 30.0
MHz
Amplifier automatically disables below 28 MHz
6 50.0 – 54.0
MHz
Table 2 Band Frequency Ranges
Caution: This amplifier has an FCC mandated automatic disconnect and other features
preventing 27-MHz operation. There is no available circuitry or control provision to
circumvent this lockout.
MARS or CAP Operation
For licensed amateur radio operators participating in Military Affiliate Radio Systems or
CAP, this amplifier is suitable for use on all frequencies between 1.8 and 54 MHz with
some precautions. The upper frequency limits are in bold type in the table above. Do not
operate above the bold-type frequency limits in the table above or PA (power amplifier)
or filter damage may occur.
This amplifier has significantly cleaner output purity than FCC part 97.307 requirements
(January 2016) when operated inside all amateur bands listed in the table above.
Ameritron does not guarantee harmonic suppression or operation in applications outside
standard amateur radio bands.
