Ametek 5000 User Manual

20 | 5000 Single-Point Moisture Analyzer
Figure 3d.
Surface mounted Model 5000 controller in
NEMA 4X enclosure.
(10.00)
254
(12.55)
319
(14.55)
369
(14.94)
379
(8.31)
211
138
(0.51)(0.31)
X SLOT, 4 PLCS
FRONT VIEW
BOTTOM VIEW
ALARM 3/4 CONDUIT
SIGNAL I/O 3/4" CONDUIT
SIGNAL I/O 3/4" CONDUIT
VALVE 3/4" CONDUIT
POWER 1/2" CONDUIT
WINDOW
NOTES:
1. XXX DIMENSIONS ARE IN MILLIMETERS; (XXX) DIMENSIONS ARE IN INCHES.
