32 | 5000 Single-Point Moisture Analyzer
Gas Connections to Analyzer
Proper sample line purge must be performed before connecting the sample line to
analyzer. Condensate in the sample line can migrate to the cell which may result in
irreparable damage to the crystal oscillator.
1. Open the main process sample line valve and pressure reducer care-
fully. Vent the line to an appropriate area and purge it with clean, dry
instrument air or nitrogen.
2. Close the process sample line valve and pressure reducer and connect
the sample line to the
1
/
8
inch sample inlet fitting.
3. Connect the conditioned reference gas line (from either the sample or
a separate source) to the
1
/
8
inch reference inlet fitting.
4. Connect vent line to analyzer
1
/
4
inch exhaust port fitting.
5. Vent the line to appropriate area.
Consult plant safety personnel for appropriate venting guidelines.

NOTE
!
CAUTION
