1.7 Wiring the Electronic Unit
• Signalconnectionsaremadetothe3terminalblockon
the front of the chassis
• Duetolowpowerconsumption,onlylightgaugewiring
is needed; shielded twisted pair cables recommended
• Integralunitsarepre-wiredtothesensingelementat
thefactory.SeeFigure2-5
• SeeFigure2-6forwiringconnectionstotheremoteunit
• Thecablefromthesensingelementisconnectedtothe
terminal strip below the instrument chassis
CAUTION-BeforeusingIntrinsicSafetyBarrierread
manufacturer instructions for barrier operation
Figure 1-5
Universal IV Wiring Connections
