105446 06 23-03-2009 43
Hysteresis of a thermostat can also be determined here. Where the
hysteresis determines the tolerence between the upper switch
temperature and the lower switch temperature of the thermostat.
Fig. 7

Press
in the main menu to select the Switch test menu.
F3F2 F4 F5F1
Two functions are available using the soft keys
Calibrator stable
Shifting temperature
Calibrator stable
Heating with Slope Rate
T
Cooling with Slope Rate
T
T
Expected switch range
for thermostat
Calibrator stable
t
[min]
T [°C/°F]
T
T
T
T
T
2
Open
Close
1
Start
Open
Close
Hyste
