40 23-03-2009 105446 06
The calibration can be stopped at any time, but this will erase
all the calibration data.
Follow the instructions on screen for repositioning the
sensors (if an external manual heat source is used) and
entering the step values (if manual input is required).
When the calibration is complete, press
or to store the
results in the calibrator. The results can be viewed using the
instructions in section 4.5.2.
4.5.2 Showing calibration results
Press
to select the Show calibration menu.
F3F2 F4 F5F1
Use
and to scroll through the list and highlight a
specific work order.
Press
to display the calibration details for the selected
work order.
The calibration results can be uploaded with the “AmeCal
Temperature” PC program. This enables you to print out the
results on a certificate.
Calibration result details
This screen enables you to scroll through the calibration steps and
view the actual SET, READ/TRUE and SENSOR temperatures for the
individual calibration steps, together with the deviation and Pass/Fail
status.
