105446 06 23-03-2009 75
F3F2 F4 F5F1
Temperature Adjustment
This enables you to check the accuracy of the heat source and the
internal sensor in the calibrator.
This can be done in 3 ways:
Using the external reference sensor on the ATC (B-version) to
measure the TRUE temperature, AmeTrim-ATC can perform a fully
automatic calibration and adjustment of the internal sensor. The
calibrated reference sensor should then be connected to the
reference input.
Using a Digital Temperature Indicator (DTI) AmeTrim-ATC can
read the TRUE temperature from the DTI and also make a fully
automatic calibration and adjustment of the internal sensor. The
DTI must be connected to a vacant serial COM port. See fig. 11.
Using any other reference instrument, AmeTrim-ATC will set the
temperature sequence and the TRUE values can be entered as
they occur as manual inputs.
