It is very important that humidity in the well and insertion
tube is removed to prevent corrosion and frost
expansion damages.
Remove the insertion tube from the calibrator using the tool for
insertion tube supplied with the instrument (see fig. 9).
Fig. 9
Tool for insertion tube
Hole for tool for insertion tube
Tool for insertion tube
Insertion tube
