Front Panel Controls
• Power On/Off
• Test
• Load Level LED Gauge
• Battery Charge LED Gauge
• Voltage Manager Boost LED
• Voltage Output On LED
• Voltage Manager Buck LED
• On Battery LED
• Replace Battery LED
• Overload LED
• Fault Code LED
• System Over Temperature LED
Rear Panel Information and Controls
• Six (6) Foot Power Cord with NEMA 5-15P Plug
• Four (4) NEMA 5-15R Receptacles
• Conguration Manager DIP Switches
• Communications Manager DB9 Port, USB Port
• Circuit Breaker
• AC Inlet Module
Internal Batteries
• User Hot-Swappable (See Instruction Manual)
• Type: 12 Volt, High Rate 21W
• Quantity: 2 Batteries
• Recharge Time: 6 Hours to 80%, 24 Hours to Full Charge
Environmental
• Temperature: 0 to 40℃ (32 to 104℉) Operating
-20 to 60℃ (-40 to 140℉) Shipment/Storage
• Humidity: 5 to 90% Non-Condensing (Operating,
Shipment/Storage)
• Altitude: 3,000m (10,000 ft) max. Operating;
12,000m (40,000 ft) max. Shipment/Storage
Safety Agency and EMC Compliance:
All Units are Listed by UL and Marked With the UL/cUL Marking
Standard UPM:
Products Listed to:
• UL1778 5th Edition
• CSA 22.2 Nos. 107.3-14
Products in Compliance with:
• FCC-Part 15, Subpart B, Sections 15.107b & 15.109b
Class A Digital Device*
• CISPR11:2009, A1; 2010, Class A*
• IEC61000-4-2, Electrostatic Discharge
• IEC61000-4-3, Radiated Electromagnetic Field Immunity
• IEC61000-4-4, Electrical Fast Transient/Burst Immunity
• IEC61000-4-5, Surge Immunity
• IEC61000-4-6, Immunity to Conducted Radio Frequency
Disturbances
• IEC61000-4-8, Power Frequency Magnetic Field Immunity
• IEC61000-4-11, Voltage Dips, Short Interruptions and
Voltage Variations
Medical UPM:
Products Listed to:
• UL60601-1 2nd and 3rd Edition
• UL1778 5th Edition
• CSA 22.2 No. 601.1-M89
• CSA 22.2 No. 107-1-M91
• CSA 22.2 Nos. 0-M1982
• CSA 22.2 Nos. 0.4-M1982
Products in Compliance with:
• FCC-Part 15, Subpart B, Sections 15.107b & 15.109b
Class A Digital Device*
• CISPR11:2009, A1; 2010, Class A*
• EN60601-1-2 : 2007
*Note: Class B is Available as an Option
Please Consult Your Powervar Sales Representative
RoHS Compliance:
All Products (Standard and Medical) are RoHS Compliant
North American Models ABCE422-11 and ABCE422-11MED
Warranty/Support: AMETEK Powervar warrants the electronics and transformers used in its uninterruptible power man-
agers to be free from defects in materials and workmanship for a period of ve years from the date of shipment. Batteries
are warranted for a period of two years from the date of shipment. For service or support on any AMETEK Powervar
product, please contact AMETEK Powervar Technical Support at (800) 369-7179 or visit the AMETEK Powervar website
at www.powervar.com.
Battery Life Disclaimer: AMETEK Powervar’s standard battery warranty applies only to UPM products which are contin-
uously connected to AC mains power, except during utility power outages. Products which are regularly and intentionally
disconnected from AC mains power will experience battery discharge/charge cycles potentially far more numerous than
those for which the battery was designed. As a result, products used in such applications will experience substantially
reduced battery life. For that reason, AMETEK Powervar’s standard battery warranty does not apply for applications
in which the UPM product is regularly and intentionally disconnected from AC mains power. AMETEK Powervar UPM
products used in such applications shall receive a 90 day warranty on batteries.
NOISE REJECTION-ISOLATION: With unit under power and an ANSI/IEEE C62.41Cat. A pulse applied either normal or
common mode at the input, the noise output voltage will be less than 10V normal mode and less than 0.5V common mode
in all four quadrants (CM-NM, NM-NM, CM-CM, NM-COM).
SURGE VOLTAGE WITHSTAND CAPABILITY: Tested under power to ANSI/IEEE C62.41 Cat. A & B (formerly
IEEEE587-1980). CAT. A - 6000V @ 200 amps, 0.5 usec risetime, 100 kHZ decay, Cat. B - 6000V @ 500 amps, 0.5 usec
risetime, 100 kHZ decay.
