Ametek Powervar Security II Series User Manual

50
A01-00055 Rev N
International Models ABCE2202-22 and ABCE2202-22MED
ABCE2202-22
51220-03R
ABCE2202-22MED
51220-23R
Type Standard Medical Grade
Power Rating (VA/Watts) 2200 / 1980 2200 / 1980
Inverter Waveform Low Distortion Sine Wave Low Distortion Sine Wave
Transfer Time 4 ms. Typical 4 ms. Typical
Frequency 50 / 60 Hz. 50 / 60 Hz.
BTU/Hr. 375 375
T.H.D. w/100% Resistive Load <4% on Battery <4% on Battery
Online Efciency (w/o Charger) 95% 95%
Input Voltage 230 230
Input Current 16.0 Amps 16.0 Amps
Output Voltage 230 230
Output Current (VA/Watts) 9.55 / 8.60 Amps 9.55 / 8.60 Amps
Input Voltage Range
(w/o Using Battery)
185 to 276 Volts 185 to 276 Volts
Output Regulation (Mains) ± 10% ± 10%
Output Regulation (On Battery) ± 5% ± 5%
Backup Time at Full Load (0.7 P.F.) > 5 Minutes > 5 Minutes
Floor Mountable Yes (Optional) Yes (Optional)
Communications Interface DB9, USB (SNMP Optional) DB9, USB (SNMP Optional)
Shipping Weight (kg) 75 75
Dimensions (in/mm) LxWxH
7.98 x 21.75 x 19.14 /
202.69 x 552.45 x 486.16
7.98 x 21.75 x 19.14 /
202.69 x 552.45 x 486.16
Output Receptacle
Eight (8) IEC320 C13 and
(1) IEC320 C19
Eight (8) IEC320 C13 and
(1) IEC320 C19
