Ametek Spectrolab LAS01 User Manual

Description of instrument
—
10 SPECTROLAB —
23.07.2020
1.3.5 Spark stand
Fig. 5
No. Component No. Component
1 Access to electrode clamp 7 Locking wheel for contact
2 Sparky stand plate 8 Electrode and spark stand insert
3 Clamp (swinging) 9 Outlet to filter system
4 Contact (movable) 10 Electrode holder
5 Start/Stop measurement 11 Holder for fiber-optics to air optics
6 On/Off switch for spark excitation
(plasma generator)
