152 ARX 1
1201281 A | 24.07.2013
K14 Relay, light
K15
** Relay, front vibration
K16 ** Relay, rear vibration
K17 Relay, brake-light
M1 Starter motor
M2 Hydraulic oil cooler
M3 Diesel pump
M4 Sprinkler pump
M11 Sprinkler pump, anti-adhesive
N1 Controller
N2 Display unit
N3 Measuring transducer, asphalt temperature
P1 Operating hours counter
R1 Pre-heating coil
R11 Seat heating
S1 Switch, ignition
S2 Switch, emergency stop
S3 Operating lever sensor, right
S4 Operating lever switch, right
S5 Potentiometer, sprinkler
S6 Switch, work gear
S7 Switch, vibration automation
S8 Switch, rear vibration
S9 Switch, horn
S10 Switch, parking light / dipped light
S11 Switch, revolving warning light, work light
S12 Switch, hazard flasher
S13 Switch, indicator
S14 ** Switch, vibration selector
S15
* Operating lever sensor left
S16 * Operating lever switch, left
S17 Switch, parking brake
S18 * Battery cut-off switch
S19
* Switch, flow divider
S20 * Switch, edge cutter, up
Element Description
K18 ** Relay, altitude solenoid power supply
K
19 **
Control unit of altitude solenoid power supply
