Appendix 153
1201281 A | 24.07.2013
(*) Optional
(**) Not available
S21 * Switch, edge cutter, down
S22 * Switch, edge cutter, water
S51 Sensor, seat contact
S52 Sensor, brake pressure
S53 Sensor, hydraulic oil temperature
S54 Sensor, diesel tank
S55 Sensor, engine oil pressure
S56 Sensor, coolant temperature
V11 Free-running diode, buzzer, flow divider
V12 * Diode, edge cutter 1
V13
* Diode, edge cutter 2
Y1 Pull-in / holding solenoid
Y2 Valve, locking brake
Y3 Drive pump, forwards
Y4 Drive pump, backwards
Y5 Valve, front vibration
Y6 Valve, rear vibration
Y7 ** Valve, large amplitude vibration
Y8
** Valve, small frequency vibration
Y9 Shut-off valve, sprinkler pump
Y11
* Valve, flow divider
Y12 * Valve, edge cutter
Y13
* Valve, edge cutter
Y14 * Valve, edge cutter water
Element Description
Y16 ** Altitude solenoid
