8 Maintenance
BNNbOO
ID: 1138310 Issue date January 01, 2010
108
Opening the hood
Unlocking the hood (1)
The hood lock (2) is located on the
left-hand side. Use the ignition key,
turned a quarter-turn clockwise, to
open the lock.
Open the hood
There is one locking device (3) on the
left and one on the right of the roller.
You must release both locks in order
to lift the hood.
Lifting the hood
Open the hood with the handle (4) on
the left of the hood.
Lift the hood with slight pressure
toward the center of the roller and
then open the hood completely.
If the hood is defective, replace it
immediately.
NOTE
Two gas absorbers reduce the force required to open the hood and give it its
final position. If you need more force to open the hood, replace the gas
absorbers.
WARNING!
Burns hazard!
• Only work on a cool engine.
• Keep enough distance to the exhaust.
1
3
2
4
