8 Maintenance
BNNbOO
ID: 1138310 Issue date January 01, 2010
112
Inspect – fuel level, hydraulic oil level
WARNING!
Danger of roll-over!
Switch off the diesel engine to avoid unintentional start-up of the machine.
Fuel tank - filling
Fill the fuel tank with fuel oil up to the
lower edge of the filler neck (1) every
day before starting work.
The tank holds 43 l of fuel.
Hydraulic oil tank - checking oil
level
Drive the roller onto a level surface -
and check the oil level in the inspect-
ion window (1).
If oil level is 20 mm below the top
edge of the inspection window, top up
hydraulic oil through the filler neck
(2).
NOTE
Pay attention to the lubricant table.
2
1
