6 Operating
BNNbOO
ID: 1138310 Issue date January 01, 2010
59
Driving and braking
Speed regulating lever (2)
Move the speed adjusting lever (2)
forward until it snaps into first
position.
The engine is now running at the first
operating speed.
The machine also operates at an
additional, higher speed, depending
on the model.
Move the speed adjusting lever (2),
without using excessive force,
forward again until it snaps into the
second position. The engine is now
running at the second operating
speed.
Check whether the steering is
working.
Forwards
Move the operating lever (1) slowly
forward.
The machine moves forward.
Braking (service brake)
Slowly pull the operating lever (1) into
neutral position.
The machine is automatically
hydrostatically braked.
2
1
2
1
2
1
