8 Maintenance
BNNbOO
ID: 1138310 Issue date January 01, 2010
122
Removing the rear water tank
Unscrew the holder screws (1).
Now pull the tank (1) approx. 10 cm
to the back.
You can now access the water hose
to the left of the seat.
Disconnect the water hose
Unscrew the quick-release (1) water
hose clamp (2) by pressing the black
plastic ring against the screw
connection. Now pull the hose off the
coupling.
You can now pull the water tank all
the way out.
1
1
1
2
