6 Operating
BNNbOO
ID: 1138310 Issue date January 01, 2010
61
Working speed
Speed regulating lever (2) –
vibration frequency selection
The machines have two operating
speeds.
This allows improved adaptation of
speed and vibration power to specific
ground conditions
NOTE
The machine may only have one
speed, depending on the options
fitted.
Idling speed
The speed adjusting lever (2) is at the
rearmost position.
Low working speed
Low speed - low frequency
Move the speed adjusting lever (2)
forward until it snaps into first
position.
The engine is now running at low
speed.
High working speed
High speed - high frequency
Move the speed adjusting lever (2)
forward again until it snaps into
second position.
The engine is now running at high
speed.
1
2
2
1
2
1
