13 Specifications
BNNbOO
ID: 1138310 Issue date January 01, 2010
174
Specifications AV2-2K
AV23-2K AV26-2K AV32-2K AV40-2K
Service weight according to
CECE (kg)
2280 2400 3110 3540
Static linear load (kg/cm) 12.1 11.1 13.2 14.6
Wheel load (kg) 278 278 383 408
Outside turning radius/inside
(mm)
3350 /
2350
3450 /
2250
3450 /
2250
3500 /
2200
Amplitude (mm) 0.42 0.45 0.41 0.33
Compaction force per roller
drum (kN)
34 / 41 38 / 46 38 / 46 36 / 48
Gradient in % with/without
vibration (N/cm)
30 / 40 30 / 40 30 / 40 25 / 35
Drive YANMAR 3TNV88 / Euromot 3A - EPA Inter 4
Output to DIN 6270 B 1.) 19.8k W / 27 PS 2.) 23.2 kW / 31.5 PS
Operating speed 1.) 2,100 1/min 2.) 2,400 1/min
Driving speed 0-10 km/h
Steering angle/pivoting ± 32° / ± 8°
Vibration frequency 1.) 58 Hz 2.) 66 Hz
Fill levels:
Water tank 80 l + 120 l
Hydraulic oil tank 25 l
Anti-adhesive tank 14 l
Fuel oil tank 43 l
