12 Wiring diagram
BNNbOO
ID: 1138310 Issue date January 01, 2010
167
Wiring diagram key
Element Description
F7 Fuse, work headlight, revolving warning light, edge cutter
F11 Fuse, pull-in solenoid
F12 Fuse, fan for oil cooler, diesel pump, alternator
F13 Fuse, reserve (15+)
F14 Fuse, reserve
G1 Alternator
G2 Battery
H1 Control lamp, charging control
H2 Control lamp, cooling water temperature
H3 Control lamp, engine oil pressure
H5 Control lamp, pre-heating
H6 Control lamp, parking light
H7 Control lamp, low beam light
H8 Control lamp, indicator
H19 Control lamp, supply pressure (brake pressure)
H24 Control lamp, emergency stop
H36 Control lamp for fuel reserve
H40 Control lamp, ROPS2D (*)
K4 Relay, indicator (*)
K14 Relay, starting interlock
K20 Relay, vibration
K24 Relay, emergency stop
K30 Timer relay
K31 Relay, pull-in solenoid
K36 Relay, automatic vibration
K38 Relay, sprinkler
K55 "Delayed seat switch" timer (*)
K80 Relay, seat contact
K90 Relay, ROPS2D (*)
M1 Starter motor
M2 Engine, fan for oil cooler
M10 Engine diesel pump
