12 Wiring diagram
BNNbOO
ID: 1138310 Issue date January 01, 2010
168
Wiring diagram key
Element Description
M14 Engine, sprinkler pump
M15 Engine, anti-adhesive pump (*)
N1 Tilt sensor, ROPS2D (*)
P6 Operating hours counter
R1 Sensor, fuel level
R3 Heating coil
S1 Battery cut-off switch (*)
S2 Ignition switch
S3 Switch, edge cutter up (*)
S4 Switch, edge cutter down (*)
S6 Sensor (switch), engine oil pressure
S7 Sensor (switch), cooling water temperature
S13 Switch, horn
S14 Switch, hazard flasher (*)
S16 Sensor (switch), oil temperature
S18 Switch, light (parking light / low beam light) (*)
S22 Switch, operating lever reverse position
S32 Sensor (switch), supply pressure (brake pressure)
S54 Switch, drive pump zero position
S55 Switch, continuous sprinkling
S56 Switch, work light (*)
S57 Switch, vibration
S58 Switch, indicator left / right (*)
S59 Switch, vibration selector (*)
S60 Switch, beacon light (*)
S61 Switch, interval sprinkler control (*)
S64 Switch, flow divider (*)
S65
Switch, Pos. 1: Revolving warning light/
Pos. 2: Work light & revolving warning light (*)
S67 Switch, emergency stop
S73 Switch, operating lever neutral position
S76 Switch, sprinkler (button) / anti-adhesive (*)
