12 Wiring diagram
BNNbOO
ID: 1138310 Issue date January 01, 2010
169
Wiring diagram key
Element Description
S80 Switch, seat contact
S81 Switch, edge cutter sprinkler (*)
S82 Switch, towing eye (*)
S83 Switch, edge cutter down / up (*)
S85 Switch, manual / automatic vibration (*)
ST1 Multifunction display unit
V11 Diode, emergency stop (self-latching, emergency stop relay)
V18
Diodes, lock diode, parking position/free-running diode, supply
(15+)
V20 Diode, free-running diode, vibration valve
V30 Diode, free-running diode to flow divider (*)
V41 Diode, free-running diode to edge cutter valve (*)
V42 Diode, free-running diode to edge cutter valve (*)
V43 Diode, free-running diode to edge cutter valve (*)
V55 Diode, lock diode "delayed seat switch" (*)
X2...X7 Connector on relay panel
X12 Connector, relay panel supply connection
X20 Connector, edge cutter switch connection
X28 Connector, edge cutter diode connection
X40 Connector, edge cutter valve connection
X42 Connector, flow divider valve connection (on AV2 only)
X50 Connector, operating lever console connection
X52 Connector, seat contact connection
X60 Plug, tilt sensor connection (*)
X62 Plug, operating lever control (*)
X70 Socket, seat heating (*)
Y14 Valve, sprinkler (**)
Y15 Valve, anti-adhesive (**)
Y16 Valve, front vibration
Y17 Valve, rear vibration (*)
Y30 Valve, flow divider (*) (only for AV2-2)
Y31 Stop solenoid; (stop solenoid; pull-in and holding solenoid)
Y41 Valve, edge cutter up (*)
