42
UPGRADE - VERSION 5.03
D.1 CODIFY PROGRAMS THROUGH BARCODE
It is possible to program & recall the the frame to be joined using a barcode.
Using a barcode scanner (see pecture D.1) the program name is conveyed to the machine
Picture D.1
Use a laser scanner, code number 805500001
The scanner must be connected to the suitable connector “A” (see picture D.1.A) which is placed on
the back side of keypad
Picture D.1.A
A
B
