CAP Zero Adjust to eliminate test lead
capacitance (±20pF).
Note: Small value capacitors can also be
measured by inserting their leads directly into
the slots in the meter.
Cx
200
n
20m
200p
200
ZERO
ADJUST
(20 )
OFF
20
2k
2M
20M
CR50
F
20
k
200
k
2m
200
20
2
20n
2n
CAP.
ZERO
ADJUST
Rx
DISCHARGE CAPACITOR
BEFORE CONNECTING
F
1
3
2
4
SAFETY TEST LEADS
The test leads included with your meter have
shrouded banana plugs to eliminate the
possibility of shock if the plugs accidentally pull
out of the meter while making a measurement.
Always inspect the test leads for damage before
making any measurements.
