AMX AXB-F117 Stealth 1 User Manual

48 AXCESS Programming AXB-F117 Stealth 1 Camera Controller
General format (Cont.)
RS-232 Levels Level
6
ZOOM_POT
7
FOCUS_POT
Request functions sent to AXB-F117
Function Syntax
Channel On/Off '*' <1> <0> <CHANNEL> <STATUS>
<CHECKSUM>status 1 -> turn on channel
status 0 -> turn off channel
Set level (byte) '*' <3> <0> <LEVEL NO> <LEVEL>
<CHECKSUM>
Send string '*' <4> <0> <# BYTES> <STRING>
<CHECKSUM>
Send command '*' <5> <0> <# BYTES> <STRING>
<CHECKSUM>
Get channel status '*' <6> <0> <CHANNEL> <CHECKSUM>
Get level status '*' <7> <0> <LEVEL> <CHECKSUM>
Get bus status '*' <8> <CHECKSUM>
Get device(s) '*' <9> <CHECKSUM>
Set response mask '*' <10> <MASK1> <MASK2> <CHECKSUM>
Send all on channels '*' <11> <0> <CHECKSUM>
Send all levels '*' <12> <0> <CHECKSUM>
Set level (word) '*' <13> <0> <LEVEL
NO><LEVEL_H><LEVEL_L><CHECKSUM>
Figure 48
Requests functions sent to
AXB-F117
Note
Valid <LEVEL NO> are 0-7.
