AMX AXB-F117 Stealth 1 User Manual

30 AXCESS Programming AXB-F117 Stealth 1 Camera Controller
Channel Commands
Use channel commands to program pan/tilt, servomotor positional, servomotor
speed, and motor mode functions. The following channel command lists are sorted
by function type and associated channel numbers.
Channel commands for pan/tilt functions
Figure 33 lists channel commands for pan/tilt functions.
Channel commands for pan/tilt functions
Channel State Function
31 On Pan right at current speed
35 On Pan left at current speed
36 On Tilt up at current speed
32 On Tilt down at current speed
40 On Pan right at maximum speed
41 On Pan left at maximum speed
43 On Tilt up at maximum speed
42 On Tilt down at maximum speed
44 On Pan right at 50%
45 On Pan left at 50%
47 On Tilt up at 50%
46 On Tilt down at 50%
Channel commands for servomotor positional mode lens functions
Figure 34 lists channel commands for servomotor positional mode lens functions.
Channel commands for servomotor positional mode lens functions
Channel State Function
3 On Zoom + at current speed (increases output voltage)
7 On Zoom - at current speed (decreases output voltage)
4 On Focus + at current speed
8 On Focus - at current speed
1 On Iris + at current speed
5 On Iris - at current speed
Figure 33
Channel commands for
pan/tilt functions
Figure 34
Channel commands for
servomotor positional mode
lens functions
