2 Introduction AXB-F117 Stealth 1 Camera Controller
• Pivots on center of pan/tilt axis of lens and is equipped with adjustable
position stops to set pan/tilt ranges.
• Supports camera and lens operations via AXlink or external RS-232
controller.
• Controls motor or servomotor drive lenses.
• Stores up to 255 preset commands for pan, tilt, zoom, focus, and iris
operations.
What's New
Changes and additions to this manual are indicated by change bars located in the
outside margins of the affected pages. An example of a change bar is shown to the
left (outside margin) of this paragraph, indicating that this paragraph and change
information is new. The new information in this revision includes:
• Maximum balanced weight supported by the AXB-F117 for lens/camera
equipment is 10 lb (4.5 kg).
• Pan and speeds are 24°/sec (pan) and 11°/sec (tilt).
• Power consumption is 6 amps @ 12 VDC.
• Revised Pre-Installation section with new circuit card control mode switches,
and lens control voltage switch.
• Added configuration settings for lens control mode and lens control voltage
switchers (for units that have switchers rather than jumpers).
Note
A servomotor is an automatic
device for controlling large
amounts of power by means
of very small amounts of
power and automatically
correcting performance of a
mechanism.
