User Manual - CTC-1402
42
No. Function Description Syntax Example
1 VIDIN_AUTO_SELECT
To set the Auto Switch
On/O
Command:
SEND_COMMAND <DEV>,”’VIDIN_AUTO_
SELECT-<ENABLE|DISABLE>’”
Return:
VIDIN_AUTO_SELECT-<ENABLE|DISABLE>
Command:
SEND_COMMAND <DEV>,”’VIDIN_AUTO_
SELECT-DISABLE’”
Return:
VIDIN_AUTO_SELECT-DISABLE
Description:
Set Auto Switch Status o
2 ?VIDIN_AUTO_SELECT
To verify the Auto Switch
Status
Command:
SEND_COMMAND <DEV>, “’?VIDIN_AUTO_
SELECT’”
Return:
VIDIN_AUTO_SELECT-<ENABLE|DISABLE>
Command:
SEND_COMMAND SWITCHER,”’?VIDIN_AUTO_
SELECT’”
Return::
VIDIN_AUTO_SELECT-ENABLE
Description:
Get Auto Switch Status. The Auto Switch
Status is on.
3 FP_LOCKOUT
To set Key Lock On/O
Command:
SEND_COMMAND <DEV>,”’FP_LOCKOUT-
<ENABLE|DISABLE>’”
Return:
FP_LOCKOUT-<ENABLE|DISABLE>
Command:
SEND_COMMAND <DEV>,”’FP_LOCKOUT-
DISABLE’”
Return:
FP_LOCKOUT-DISABLE
Description:
Set Key Lock o
4 ?FP_LOCKOUT
To verify the Key Lock
Status
Command:
SEND_COMMAND <DEV>, “’?FP_LOCKOUT’”
Return:
FP_LOCKOUT-<ENABLE|DISABLE>
Command:
SEND_COMMAND SWITCHER,”’?FP_LOCKOUT’”
Return:
FP_LOCKOUT-ENABLE
Description:
Get Key Lock status. The Key Lock status is on.
5 CI<input>O<output>
To execute a switch
Command:
SEND_COMMAND <DEV>,
“’CI<input>O<output>’”
Return:
SWITCH-I#,OALL
Description:
I#: #={1 ~ 7}
//{
1: VGA- IN;
2: DP_IN;
3: TX_HDMI_IN;
4: USB-C_IN;
5: RX_HDBT_IN;
6: RX_HDMI IN1;
7: RX_HDMI_IN2;
}
<output>
{ALL}
Command:
SEND_COMMAND SWITCHER,”’CI2OALL’”
Return:
SWITCH-I2,OALL
Description:
Switches HDMI IN1 to Outputs
NetLinx Commands
