User Manual - CTC-1402
7
Specications
Technical
Input 1 x HDMI IN
1 x DisplayPort IN
1 x USB-C IN
1 x VGA IN
1 x Audio IN (followed with VGA IN)
Input Signal Type HDMI with 4K@60Hz 4:4:4 8bit, HDCP 2.2;
DP/USB-C : DP 1.2a
Input Resolution
Supported
HDMI Input Resolution supported:
VESA:
800x600
8
, 1024x768
8
, 1280x768
8
,
1280x800
8
, 1280x960
8
, 1280x1024
8
,
1360x768
8
, 1366x768
8
, 1440x900
8
,
1600x900
8
, 1600x1200
8
, 1680x1050
8
1920x1080
8
,
SMPTE:
1920x1200
8
,2560x1440
8
,2560x1600
8
3840x2160P
2,3,5,6,8(YUV4:2:0)
,
4096x2160
2,3,5,6,8 (YUV 4:2:0)
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94
Hz, 8 = at 60 Hz
Established Timing including interlaced formats:
1280 x 1024 @ 75 Hz
1152 x 870 @ 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz, 87 Hz
832 x 624 @ 75 Hz
800 x 600 @ 56 Hz, 60 Hz, 72 Hz, 75 Hz
720 x 400 @ 70 Hz, 88 Hz
640 x 480 @ 60 Hz, 67 Hz, 72 Hz, 75 Hz
CEA Video Information Code (VIC) Formats:
VIC = 1, 640 x 480p 59.94/60 Hz 4:3
VIC = 2, 720 x 480p 59.94/60 Hz 4:3
VIC = 3, 720 x 480p 59.94/60 Hz 16:9
VIC = 4, 1280 x 720p 59.94/60 Hz 16:9
VIC = 5, 1920 x 1080i 59.94/60 Hz 16:9
VIC = 6, 720(1440) x 480i 59.94/60 Hz 4:3
VIC = 7, 720(1440) x 480i 59.94/60 Hz 16:9
VIC = 14, 1440 x 480p 59.94/60 Hz 4:3
VIC = 15, 1440 x 480p 59.94/60 Hz 16:9
VIC = 16, Native 1920 x 1080p 59.94/60 Hz 16:9
VIC = 17, 720 x 576p 50 Hz 4:3
VIC = 18, 720 x 576p 50 Hz 16:9
VIC = 19, 1280 x 720p 50 Hz 16:9
VIC = 20, 1920 x 1080i 50 Hz 16:9
VIC = 21, 720(1440) x 576i 50 Hz 4:3
VIC = 22, 720(1440) x 576i 50 Hz 16:9
VIC = 29, 1440 x 576p 50 Hz 4:3
VIC = 30, 1440 x 576p 50 Hz 16:9
VIC = 31, 1920 x 1080p 50 Hz 16:9
VIC = 32, 1920 x 1080p 23.97/24 Hz 16:9
VIC = 33, 1920 x 1080p 25 Hz 16:9
VIC = 34, 1920 x 1080p 29.97/30 Hz 16:9
VIC = 39, 1920 x 1080i 50 Hz 16:9
VIC = 41, 1280 x 720p 100 Hz 16:9
VIC = 42, 720 x 576p 100 Hz 4:3
VIC = 43, 720 x 576p 100 Hz 16:9
VIC = 44, 720(1440) x 576i 100 Hz 4:3
VIC = 45, 720(1440) x 576i 100 Hz 16:9
VIC = 47, 1280 x 720p 119.88/120 Hz 16:9
VIC = 48, 720 x 480p 119.88/120 Hz 4:3
VIC = 49, 720 x 480p 119.88/120 Hz 16:9
VGA Input Resolution supported:
Up to 1920 x 1200 @ 60Hz
Input Video Level 0.5-1.0 V p-p
Maximum Pixel Clock 600 MHz
Output 1 x HDBT OUT
Transmitter
