User Manual - CTC-1402
8
Output Signal Type HDMI with 4k@60Hz 4:4:4 8-bit
HDBT 2.0
Video Impedance 100 Ω
Audio Format
Support-ed
PCM 2.0
General
Operating
Temperature
0°C to 50°C (32°F to 125.6°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity 5% to 85%, non-condensing
ESD Protection Human-body Model:
±10kV(Air-gap discharge)/±5kV(Contact discharge)
Surge Protection Voltage: ±1 kV
Power Supply 12V, 3A
Power Consumption
(Max)
2K: 13.36W
4K: 17.38W (4K full loaded)
Device Dimension
(W x H x D)
220mm x 42mm x 160mm /8.66’’ x 1.65’’ x 6.30’’
Product Weight 0.97kg/2.14lb
Certication CE/FCC/ETL/PSE/RCM
Receiver
Technical
Input 1 x HDBT IN
2 x HDMI IN
Input Signal Type HDMI with 4k@60Hz with Chroma sub-sampling 4:4:4 8bit
HDBT 2.0
Resolution Support VESA:
800x600
8
, 1024x768
8
, 1280x768
8
,
1280x800
8
, 1280x960
8
, 1280x1024
8
,
1360x768
8
, 1366x768
8
, 1400x1050
8
1440x900
8
, 1600x900
8
,1600x1200
8
,
1680x1050
8
, 1920x1080
8
, 1920x1200
8
,
SMPTE:
1280x720
6,8
,1920x1080P
6,7,8
, 3840x2160
2,3,5,6,8
, 4096x2160
2,3,5,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz,
7 = at 59.94 Hz, 8 = 60 Hz;
Input Video Level 0.5-1.0 V p-p
Maximum Pixel Clock 600MHz
Output 1 x HDMI OUT
Output Signal Type HDMI
Video Impedance 100 Ω
Audio Format Sup-
ported
PCM 2.0
General
Operating
Temperature
0°C to 50°C (32°F to 125.6°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity 5% to 85%, non-condensing
Surge Protection Voltage: ±1 kV
