User Manual - CTC-1402
9
Power Supply DC12V 3A
Power Consumption
(Maximum)
2K: 22.8W
4K: 25.36W
Device Dimension
(W x H x D)
220mm x 42mm x 160mm /8.66’’ x 1.65’’ x 6.30’’
Product Weight 0.95kg/2.09lb
ESD Protection Human-body Model:
±10kV(Air-gap
discharge)
0.97kg/2.14lb
±5kV(Contact
discharge)
CE/FCC/ETL/PSE/RCM
Certication CE/FCC/ETL/PSE/RCM
Transmission Distance:
Note: Straight-through category cables wired to T568B standard recommended.
Cable Type Range Supported Video
HDMI Input/Output:15m/50ft 1080p@60Hz, 24bpp
Input/ Output: 10m/33ft 4K@30Hz 4:4:4
Input/Output: 5m/16ft
4K@60Hz, 4:4:4
Shielded Cat 6a/7 100m/330ft 1080p@60Hz
80m/ 262 ft 4K@30Hz, 4:4:4
4K@60Hz, 4:2:0
4K@30Hz, 4:4:4
