MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
MVP-5150 Specifications (Cont.)
Panel LCD Parameters (Cont.):
Type: WVGA
Aspect Ratio (WH): 16:9
Brightness (luminance): 300 cd/m2
Channel transparency: 8-bit Alpha blending
Contrast ratio: • FG5966-07: 400:1
• FG5966-09: 600:1
Display colors: • FG5966-07: 262,144 colors (18-bit color depth)
• FG5966-09: 16M colors (24-bit color depth)
Dot/pixel pitch: • FG5966-07: 0.23 mm
• FG5966-09: 0.135 x 0.135 mm
Panel type:
TFT Color Active-Matrix
Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
Viewing angles: FG5966-07:
• Vertical: + 40° (up from center) and - 80° (down from center)
• Horizontal: + 60° (left from center) and - 60° (right from center)
FG5966-09:
• Vertical: +50° (up from center) and -70° (down from center)
• Horizontal: +70° (left from center) and -70° (right from center)
External Components:
Connector: 5-pin Mini-USB connector used for output to USB programming, firmware
update, and touch panel file transfer between the PC and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible)
cable, be sure to power the panel On before attempting to connect the USB
cable from the PC to the mini-USB port on the panel.
DC power port: 2.5 mm port to power the panel away from a Charging Station.
Speaker: •4 Ohm
• 2 Watts 300Hz cutoff frequency
• NOTE: Speaker is only used for feedback beeps, and will not transmit
standard audio.
Audio Standards: • G.711 sound standard
• 75dB SPL@1m
IR Emitters: Transmit IR over 20 feet (6.10 m) from the panel.
• IR emitters on G4 panels share the device address number of the panel.
• Transmits AMX fixed frequencies at 38KHz and 455KHz and 8 user-
programmable frequencies from 20KHz to 1.5MHz
Operating/Storage
Environment
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 5% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories: • MVP-5150 Installation Guide (93-5966-08)
• PS3.0 Power Supply (FG423-30)
