Battery Life and Replacement
151
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Specifications
READ THESE INSTRUCTIONS FIRST!
To minimize the risk of damage to the battery during installation, all replacement MVP-BP-51 batteries
come in a protective metal cover.
Replacing The Battery
To remove an old battery and replace it:
1. Remove the battery from its packaging and inspect it for any damage or distortion. If the battery
shows evidence of damage, contact AMX for replacement and proper disposal information.
2. Place the device face-down on a surface that will not scratch the unit and remove the five screws
from the back of the device (FIG. 84).
MVP-BP-5X Battery Pack Kit (FG5966-27) Specifications
Dimensions: 4 1/8” x 2 1/2” x 3/8” (10.48 cm x 6.35 cm x 0.95 cm)
Weight: 0.35 lbs (158.76 g)
Certifications: • CE (pending)
• IEC/EN-60950
•RoHS
• UN/IATA
• UL (pending)
Operating/
Storage
Environment
• Operating Temperature: 0° C (32° F) to 45° C (113° F)
• Operating Humidity: 20% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F) for periods of less than one
month, -20° C (-4° F) to 45° C (113° F) for less than three months but greater than one
month, and -20° C (-4° F) to 20° C (68° F) for less than one year but greater than three
months
• Storage Humidity: 5% - 85% RH
Included Parts • Replacement MVP-5100/5150 battery (57-0016-SA)
• Upper rubber feet (screw covers, black, 60-5966-13BL)
• Large rubber foot with adhesive, (60-5966-44)
• Upper screws (5), (80-0125-01)
• Replacement battery cover screws (2), (80-0108-05)
IMPORTANT: Do NOT discharge the battery before installing the latest MVP-5100/
5150 firmware (v2.66.17 or later), available at www.amx.com. Prior to battery
removal, run the device until the battery is completely discharged.
