EVAL-ADuCM355QSPZ Evaluation Board UG-1308

Rev. A | Page 7 of 24

CONNECTING AN ELECTROCHEMICAL SENSOR

The ADuCM355 has two measurement channels (CH0 and CH1)

for electrochemical sensors. A 2-lead, 3-lead, or 4-lead sensor

can be connected to either CH0 or CH1. Figure 7 shows an

electrochemical sensor connected to CH1.

16887-007

Figure 7. Sensor Connector
