EVAL-ADuCM355QSPZ Evaluation Board UG-1308
Rev. A | Page 23 of 24
ORDERING INFORMATION
To view the complete EVAL-ADuCM355QSPZ schematic, visit https://www.analog.com/media/en/technical-documentation/evaluation-
documentation/EVAL-ADuCM355-RevBSchematic.pdf.
To view the PCB layout, visit https://www.analog.com/media/en/technical-documentation/evaluation-documentation/EVAL-
ADuCM355-EvalBrd_Layout.pdf.
BILL OF MATERIALS
Table 2.
Name Value Part Description Manufacturer Part No.
AVDD, DVDD 25.195.0253.0 Connector PCB terminal block 3.5 mm
Wieland Electric
GMBH
25.195.0253.0
C1, C2, C14,
C34, C35, C36
0.1 μF Ceramic capacitor, X7R Wurth Elektronik 8.85012E+11
C9 to C12, C17
to C21, C28,
C29
0.1 μF Ceramic capacitor, X5R, ultrabroadband
American Technical
Ceramics
545L104KT10C
C13 220 pF Ceramic capacitor, X7R Kemet C0402C221J5RACTU
C23, C25 to
C27, C30, C31
0.47 μF Ceramic capacitor, X5R, 0402 Taiyo Yuden LMK105BJ474KV-F
C24 4.7 μF Ceramic capacitor, X6S, general-purpose Murata GRM185C81A475KE11D
C32, C33 7 pF Ceramic capacitor NP0 (C0G), high frequency, high-Q Murata GJM1555C1H7R0CB01D
C37 to C41,
C47, C49, C53
to C55
0.1 μF Ceramic chip capacitor, X8R TDK C1608X8R1E104K080AA
C42, C46, C48,
C52, C57
10 μF
Tanceram® chip capacitor, X5R, low equivalent series
resistance (ESR)
Johanson
Dielectrics
250R18X106KV4E
C43 to C45 1 μF Ceramic capacitor, Y5V Yageo CC0603ZRY5V6BB105
CH0, CH1 CO-A4 4-lead electrochemical sensor socket Alphasense CO-A4
C_LPF0, C_LPF1 4.7 μF Ceramic capacitor, 0805, X5R Taiyo Yuden EMK212BJ475KG-T
DS1 SML-310MTT86 LED, green surface mount ROHM SML-310MTT86
DS2 LNJ926W8CRA LED, blue surface mount Panasonic LNJ926W8CRA
E1, E2 80 Ω at 100 MHz Ferrite bead, 0.1 Ω maximum dc resistance, 1 A
Murata
Manufacturing
BLM41PF800SN1L
E3, E4 60 Ω at 100 MHz Inductor chip ferrite, 0.02 Ω dc resistance, 3.5 A Murata BLM21PG600SN1D
JP4, JP5, JP7 to
JP20
0 Resistance jumper Panasonic ERJ-6GEY0R00V
JP25 to JP36,
JP38 to JP46
M20-9990245
Connector PCB, straight male jumper, 2-position,
M020779
Harwin M20-9990245
JP6 0 Use existing E004447 Panasonic ERJ-3GSYJ0.0
P1 TSW-110-08-G-S Connector PCB, straight header 10-position Samtec TSW-110-08-G-S
P14, P26 TSW-101-07-G-D Connector PCB, dual straight header, 2-position Samtec TSW-101-07-G-D
P2 TSW-120-07-S-S
Connector PCB, 20-position, unshrouded male
header, 0.64 mm square post, 2.5 4 mm pitch, 5.84
mm post height, 2.54 mm solder tail
Samtec TSW-120-07-S-S
P27
TSW-104-25-F-D-
RA
Connector PCB header, 2.54 mm square post, dual
row, right angle
Samtec TSW-104-25-F-D-RA
P3 2520-6002-UB Connector PCB header, straight male, 20-position 3M 2520-6002UB
P4 47346-0001 Connector PCB microUSB receptacle Molex 47346-0001
P5 IPS1-109-01-L-D
Connector PCB, 18-position, female header,
shrouded dual row, straight, 2.54 mm solder tail, 2.54
mm pitch
Samtec IPS1-109-01-L-D
Q1, Q2 MMBFJ177
Precision channel junction field effect transistor
(JFET) switch
Fairchild
Semiconductor
MMBFJ177
R1, R2 150 kΩ Precision thick film chip resistor, R0603 Panasonic ERJ-3EKF1503V
R10, R17 560 Ω Thick film chip resistor Multicomp (SPC) MC0063W06031560R
R14 0 Ω Thick film chip resistor Multicomp (SPC) MC00625W040210R
