Aneng Q1 User Manual

19
Function Range
Resolution
Accuracy
DC Current
(mA&A)
999.9mA
0.1mA
±(1.0%+3)
9.999A
0.001A
DC Current
(μA)
99.99μA
0.01μA
±(0.8%+3)
999.9μA
0.1μA
AC Current
(mA&A)
999.9mA
0.1mA
±(1.2%+3)
9.999A
0.001A
AC Current
(μA)
99.99μA
0.01μA
±(1.0%+3)
999.9μA
0.1μA
Frequency response of AC Current: 40Hz-1kHz
Resistance
99.99Ω
0.01Ω
±(1.0%+3)
999.9Ω
0.1Ω
±(0.5%+3)
9.999kΩ
0.001kΩ
99.99kΩ
0.01kΩ
999.9kΩ
0.1kΩ
9.999MΩ
0.001MΩ
±(1.5%+3)
99.99MΩ
0.01MΩ
±(3.0%+5)

Aneng Q1 Specifications

General

Display Type	LCD
Continuity Test	Yes
Diode Test	Yes
Power Supply	2 x AAA batteries
NCV	Yes
Data Hold	Yes
Backlight	Yes
Auto Power Off	Yes
DC Current Range	0-10A
AC Current Range	0-10A
Resistance Range	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
Capacitance Range	10nF/100nF/1μF/10μF/100μF/1mF/10mF
Frequency Range	0-10MHz
Duty Cycle	1% to 99%
Temperature Range	-20°C to 1000°C
