Aneng Q1 User Manual

Function Range
Resolution
Accuracy
Capacitance
9.999nF
0.001nF
±(5.0%+20)
99.99nF
0.01nF
±(2.0%+5)
999.9nF
0.1nF
9.999μF
0.001μF
99.99μF
0.01μF
999.9μF
0.1μF
9.999mF
0.001mF
±(5.0%+5)
Frequency
(Measures
only to
100kHz
under the
ACV setting)
99.99Hz
0.01Hz
±(0.1%+2)
999.9Hz
0.1Hz
9.999kHz
0.001kHz
99.99kHz
0.01kHz
999.9kHz
0.1kHz
5.000MHz
0.001MHz
Duty Cycle
1%~99%
0.1%
±(0.1%+2)
20

Aneng Q1 Specifications

General

Display Type	LCD
Continuity Test	Yes
Diode Test	Yes
Power Supply	2 x AAA batteries
NCV	Yes
Data Hold	Yes
Backlight	Yes
Auto Power Off	Yes
DC Current Range	0-10A
AC Current Range	0-10A
Resistance Range	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
Capacitance Range	10nF/100nF/1μF/10μF/100μF/1mF/10mF
Frequency Range	0-10MHz
Duty Cycle	1% to 99%
Temperature Range	-20°C to 1000°C
