Anet A8 Plus - Page 19

Step 8
No.
Name
Qty.
1
M4*25
4
2
Spring
4
3
Plastic hand screw
4
4
Heating bed300*300*3mm
1
5
Toughened glass
1
6
Clips
4
M4*25
Attention: Fix the hot bed on the heating bed support in sequence as shown in the picture.
M4*25
Heating bed
Spring
Hotbed support
Plastic hand screw
Before assembly
After assembly
